- Battery Type:zn/mno2
- Size:11.6*4.2mm
- Model name:AG12 LR43 186
- Approx weight:1.5g
- Dimensio:11.6*4.2mm
- Safety report:MSDS
- Type:LR43 AG12 1.5V alkaline button cell battery
- Application:Toys
- Application:Power Tools
- Application:Home Appliances
- Application:Consumer Electronics
- Application:Remote control
- Shape:Button
- Place of Origin:CN;GUA
- Battery Size:LR43
- Brand Name:Eunicell or Neutral
- Certification:CE/ROHS/REACH/SGS/MSDS
- Model Number:AG12 / LR43
LR43 Coin Cell Button battery AG12 SR43W SR43 1.5V alkaline
Product Name: 1.5V Alkaline Button Battery
Model Number: AG12/LR43/186
Place of Origin: ChinaProduct Details
Features & Specifications
Nominal Voltage: 1.5V
Capacity: 123mAh
Approx. Weight: 1.5G
Dimension(mm): ¦11.6*4.2
Chemical System Zinc Manganese Dioxide
Model | No. | Dia (mm) | H (mm) | Voltage (V) | Capacity(mAh) | (Ω) | Dishcarg time(hrs) | Off Voltage(V) | Weight (g) |
LR621,364 | AG1 | 6.75 | 2.00 | 1.5 | 13 | 68K | 630 | 0.9 | 0.25 |
LR726,396 | AG2 | 7.85 | 2.50 | 1.5 | 26 | 22K | 490 | 0.9 | 0.44 |
LR41,392 | AG3 | 7.85 | 3.50 | 1.5 | 35 | 22K | 670 | 0.9 | 0.57 |
LR626,377 | AG4 | 6.75 | 2.50 | 1.5 | 18 | 47K | 690 | 0.9 | 0.31 |
LR754,393 | AG5 | 7.85 | 5.30 | 1.5 | 58 | 22K | 920 | 0.9 | 0.9 |
LR920,371 | AG6 | 9.45 | 2.00 | 1.5 | 32 | 15K | 320 | 0.9 | 0.55 |
LR926,395 | AG7 | 9.45 | 2.50 | 1.5 | 46 | 15K | 400 | 0.9 | 0.64 |
LR1120,391 | AG8 | 11.55 | 2.00 | 1.5 | 45 | 15K | 570 | 0.9 | 0.79 |
LR936 | AG9 | 9.45 | 3.50 | 1.5 | 56 | 15K | 550 | 0.9 | 0.86 |
LR1130,389 | AG10 | 11.55 | 3.00 | 1.5 | 68 | 15K | 850 | 0.9 | 1.11 |
LR721,362 | AG11 | 7.85 | 2.00 | 1.5 | 20 | 7.5K | 415 | 0.9 | 0.38 |
LR43,386 | AG12 | 11.55 | 4.10 | 1.5 | 100 | 7.5K | 610 | 0.9 | 1.47 |
LR44,357 | AG13 | 11.55 | 5.3 | 1.5 | 148 | 7.5K | 880 | 0.9 | 1.92 |
