- Place of Origin:CN;GUA
- Certification:ce
- Battery Type:Li-socl2
- Certification:ROHS, REACH, SGS, MSDS
- Brand Name:Eunicell
- Model Number:ER18335
- Size:18*50.5mm
- Nominal Voltage:3.6v
- battery type:Li-socl2
- Safety report:MSDS
ER18335 lithium thionyl chloride battery LiSOCl2 3.6v ER18335 high energy battery
Product Description
- Construction: bobbin type
- Dimension (D x H): 18.5 x 33.5mm
- Weight: 13g
- Rated voltage: 3.6V
- Terminal voltage: 2.0V
- Rated capacity: 3300mAh
- Maximum continuous operating current: 75mAh
Main applications:
- General purpose; camera
- Electronic cells; medical equipment; military
- Aerospace; telecommunications; water
- Electricity meter, backup power for circuit board
- LED lighting applications
- Others.
| Model | Rated voltage | Nominal Capacity | Working Current(mA) | Dimensions(mm) | Weight(g) | |||
| (V) | (mAh) | Standard current | Continues Current | Pluse Current | Diameter*Height | |||
| High Capacity | ||||||||
| ER10280 | 3.6V | 450mAh | 1mA | 10mA | 30mA | 10.5mm*28mm | 4g | |
| ER13150 | 3.6V | 450mAh | 1mA | 10mA | 30mA | 13.5mm*15.5mm | 6g | |
| ER10450 | AAA | 3.6V | 750mAh | 1mA | 25mA | 60mA | 10.4mm*45.3mm | 9g |
| ER14250 | 1/2AA | 3.6V | 1200mAh | 1mA | 20mA | 45mA | 14.5mm*25.2mm | 10g |
| ER14335 | 2/3AA | 3.6V | 1600mAh | 1mA | 75mA | 150mA | 14.5mm*33.5mm | 12g |
| ER14505 | AA | 3.6V | 2400mAh | 2mA | 100mA | 200mA | 14.5mm*50.5mm | 19g |
| ER17335 | 2/3A | 3.6V | 2000mAh | 1mA | 100mA | 200mA | 17.0mm*33.5mm | 18g |
| ER17505 | A | 3.6V | 3500mAh | 2mA | 120mA | 200mA | 17.0mm*50.5mm | 24g |
| ER18505 | A | 3.6V | 3800mAh | 3mA | 120mA | 200mA | 18.5mm*50.5mm | 28g |
| ER26500 | C | 3.6V | 8500mAh | 4mA | 130mA | 300mA | 26.2mm*50mm | 52g |
| ER34615 | D | 3.6V | 19000mAh | 5mA | 200mA | 400mA | 32.9mm*61.5mm | 100g |
| ER341245 | DD | 3.6V | 35000mAh | 10mA | 400mA | 500mA | 32.9mm*124.5mm | 195g |
| ER9V | 9.0V | 1200mAh | 1.5mA | 40mA | 100mA | 17.0*26.0*50 | 31g | |
